C-Band Optical RF Uplink PL7CU30T / PL7CU30R4

Our Platinum C-Band products are designed to provide full specification service up to a full 4dB optical budget at low cost. The uplink: supports up to a full 4dB optical budget... Read full description

SKU: PL7CU30T / PL7CU30R4

Categories: SATCOM

Our Platinum C-Band products are designed to provide full specification service up to a full 4dB optical budget at low cost.

The uplink:

  • supports up to a full 4dB optical budget
  • has a C-Band frequency range of 5800–6800MHz
  • powerful management capabilities via a front panel LCD and rack mounted SNMP
  • user monitoring and control of required IMD levels
  • variety of RF and optical connectors
  • 1550nm and CWDM ITU Grid laser options are available for longer fiber runs and single fiber multiplexing solutions
RF Specification Value
Frequency Range - Bandwidth 5800–6800 MHz
Amplitude Response @ Unity Gain +/- 2
Noise Figure 20 to 40
Output IP3 (OIP3) 20
Input Signal Range - Total Power -25 to -5
RF Output Signal Range - Total Power 0 to -25
Optical Specifications
Optical Budget / Distance 1310nm 1550nm 8|15


For more details and prices please use the product enquiry form or contact our sales team.

Specifications

Download the C-Band Optical RF Uplink PL7CU30T / PL7CU30R4 specifications.

Single_C_band_PL7CU30T_PL7CU30R4_GF.pdf
